Single-Side Arm Parking Shed
One column supports a cantilevered arm that carries the modules over a row of bays, keeping the bays open on one side.
FERO design drawings. Photos of installed structures are on the project pages linked below.
The single side arm keeps the bays open on one side, which helps vehicle movement and gives clear manoeuvring space. Column spacing is set from the bay width to keep columns out of the way of doors, and footings are sized for overturning, since wind loads on an open canopy are high.
Single-Side Arm Parking Shed specifications
FERO Single-Side Arm Parking Shed
10 year warranty| Application | Car park |
|---|---|
| Material and grade | SS400 iron |
| Coating | Hot-dip galvanized to ASTM A123, 90 microns |
| Fasteners | Galvanized for the structure, SS304 for the modules |
| Inclination | 5 to 15 degrees, customizable |
| Design wind speed | 35 m/s (126 km/h), customizable |
| Warranty | Every FERO structure carries a 10 year warranty, galvanized iron and anodized aluminium alike. Galvanized iron is hot-dip coated to ASTM A123 at 90 microns, the basis of the warranty. Ask us for the written terms and we will send them with your quotation. |
Member sizes, spans and foundations are designed for each project. Not sure which structure fits your site? Read the guide to solar structure types.
Common questions
Which coating is used?
SS400 iron, hot-dip galvanized to ASTM A123 after fabrication, with a 90 micron coating.
How does the single side arm differ from the double side arm?
The single side arm covers one row of bays from one column line and leaves that side open. The double side arm puts arms on both sides of a central column line to cover two rows.
Are dimensions customizable?
Yes. Column height, spacing, inclination, foundation and wind design are set per site.
